Intel 6 SERIES CHIPSET - DATASHEET 01-2011 - Setup and Hold Times; Float Delay; Pulse Width; Valid Delay from Rising Clock Edge

Electrical Characteristics
340 Datasheet
Figure 8-12. Valid Delay from Rising Clock Edge
Figure 8-13. Setup and Hold Times
Figure 8-14. Float Delay
Figure 8-15. Pulse Width
Clock 1.5V
Valid Delay
VT
Output
Clock
VTInput
Hold TimeSetup Time
VT
1.5V
Input VT
Output
Float
Delay
VT
Pulse Width
VT
