Signal Description
76 Datasheet
2.22 Intel
®
Flexible Display Interface (Intel
®
FDI)
Table 2-22. Intel
®
Flexible Display Interface Signals
Signal Name Type Description
FDI_RXP[3:0] I Display Link 1 positive data in
FDI_RXN[3:0] I Display Link 1 negative data in
FDI_FSYNC[0] ODisplay Link 1 Frame sync
FDI_LSYNC[0] O Display Link 1 Line sync
FDI_RXP[7:4] I Display Link 2 positive data in
FDI_RXN[7:4] I Display Link 2 negative data in
FDI_FSYNC[1] ODisplay Link 2 Frame sync
FDI_LSYNC[1] O Display Link 2 Line sync
FDI_INT O Used for Display interrupts from PCH to processor.
