Intel 6 SERIES CHIPSET - DATASHEET 01-2011 - Mobile Intel; Series Chipset Skus

Introduction
52 Datasheet
NOTES:
1. Contact your local Intel Field Sales Representative for currently available PCH SKUs
2. Table above shows feature difference between the PCH SKUs. If a feature is not listed in
the table it is considered a Base feature that is included in all SKUs
3. The PCH provides hardware support for AHCI functionality when enabled by appropriate
system configurations and software drivers.
4. SATA 6 Gb/s support on port 0 and port 1. SATA ports 0 and 1 also support 3 Gb/s and
1.5 Gb/s.
5. USB ports 6 and 7 are disabled on 12 port SKUs.
§ §
Table 1-3. Mobile Intel
®
6 Series Chipset SKUs
Feature Set
SKU Name
HM67 HM65
PCI Express* 2.0 Ports 8 8
PCI Interface No No
USB* 2.0 Ports 14 12
5
Total number of SATA ports 6 6
• SATA Ports (6 Gb/s, 3 Gb/s, and 1.5 Gb/s) 2
4
2
4
• SATA Ports (3 Gb/s and 1.5 Gb/s only) 4 4
HDMI/DVI/VGA/SDVO/DisplayPort*/eDP*/LVDS Yes Yes
Integrated Graphics Support with PAVP 2.0 Yes Yes
Intel
®
Rapid
Storage
Technology
AHCI Yes Yes
RAID 0/1/5/10 Support Yes No
Intel
®
Anti-Theft Yes Yes
