Intel 6 SERIES CHIPSET - DATASHEET 01-2011 - (Mobile Only)

Electrical Characteristics
300 Datasheet
2. Icc (RTC) data is taken with VccRTC at 3.0 V while the system in a mechanical off (G3) state at room
temperature.
3. Numbers based on a worst-case of 3 displays - 2 DisplayPort and 1 CRT, even though only 2 display pipes
are enabled at any one time. If no CRT is used, VccADAC contribution can be ignored.
4. S0 Idle is based on 1 DisplayPort Panel used on Display Pipe A.
5. S0 Iccmax Measurements taken at 110 °C and S0 Idle/Sx Iccmax measurements taken at 50 °C.
Table 8-6. Measured I
CC
(Mobile Only) (Sheet 1 of 2)
Voltage Rail
Voltage
(V)
S0 Iccmax
Current
Integrated
Graphics
5
(A)
S0 Iccmax
Current
External
Graphics
5
(A)
S0 Idle
Current
Integrated
Graphics
4,5
(A)
S0 Idle
Current
External
Graphics
5
(A)
Sx
Iccmax
Current
5
(A)
Sx Idle
Current
(A)
G3
V_PROC_IO 1.05 0.001 0.001 0.001 0.001 0 0 —
V5REF 5 0.001 0.001 0.001 0.001 0 0 —
V5REF_Sus 5 0.001 0.001 0.001 0.001 0.001 0.001 —
Vcc3_3 3.3 0.228 0.228 0.035 0.035 0 0 —
VccADAC3 3.3 0.001 0.001 0.001 0.001 0 0 —
VccADPLLA 1.05 0.075 0.01 0.07 0.005 0 0 —
VccADPLLB 1.05 0.075 0.01 0.01 0.005 0 0 —
VccCore
(Internal
Suspend VR
mode using
INTVRMEN)
1.05 1.3 1.14 0.36 0.28 0 0 —
VccCore
(External
Suspend VR
mode using
INTVRMEN)
1.05 1.2 1.04 0.31 0.23 0 0 —
VccDMI 1.1 0.042 0.042 0.001 0.001 0 0 —
VccIO3 1.05 3.709 3.187 0.458 0.319 0 0 —
VccASW 1.05 0.903 0.903 0.203 0.203 0.603 0.23 —
VccSPI 3.3 0.01 0.01 0.001 0.001 0.01 0.01
VccDSW3_3 3.3 0.001 0.001 0.001 0.001 0.003 0.001 —
VccDFTERM 1.8 0.002 0.002 0.001 0.001 0 0 —
VccRTC 3.3 N/A N/A N/A N/A N/A N/A
6 uA
See notes
1, 2
VccSus3_3
(Internal
Suspend VR
mode using
INTVRMEN)
3.3 0.065 0.065 0.009 0.009 0.119 0.031 —
VccSus3_3
(External
Suspend VR
mode using
INTVRMEN)
3.3 0.065 0.065 0.005 0.005 0.059 0.014 —
VccSusHDA 3.3 0.01 0.01 0.001 0.001 0.001 0.001 —
