Datasheet 51
Introduction
1.3 Intel
®
6 Series Chipset SKU Definition
NOTES:
1. Contact your local Intel Field Sales Representative for currently available PCH SKUs.
2. Table above shows feature differences between the PCH SKUs. If a feature is not listed in
the table it is considered a Base feature that is included in all SKUs
3. The PCH provides hardware support for AHCI functionality when enabled by appropriate
system configurations and software drivers.
4. SATA 6 Gb/s support on port 0 and port 1. SATA ports 0 and 1 also support 3 Gb/s and
1.5 Gb/s.
5. PCI Legacy Mode may optionally be used allowing external PCI bus support through a
PCIe-to-PCI bridge. See Section 5.1.1 for more details.
Table 1-2. Desktop Intel
®
6 Series Chipset SKUs
Feature Set
SKU Name(s)
H67 P67
PCI Express* 2.0 Ports 8 8
PCI Interface No
5
No
5
USB 2.0 Ports 14 14
Total number of SATA ports 6 6
SATA Ports (6 Gb/s, 3 Gb/s, and 1.5 Gb/s) 2
4
2
4
SATA Ports (3 Gb/s and 1.5 Gb/s only) 4 4
HDMI/DVI/VGA/DisplayPort*/eDP* Yes No
Integrated Graphics Support with PAVP Yes No
Intel
®
Rapid
Storage
Technology
AHCI Yes Yes
RAID 0/1/5/10 Support Yes Yes
Intel
®
AT No No
