Signal Description
84 Datasheet
2.25 Manageability Signals
The following signals can be optionally used by Intel Management Engine supported
applications and appropriately configured by Intel Management Engine firmware. When
configured and used as a manageability function, the associated host GPIO
functionality is no longer available. If the manageability function is not used in a
platform, the signal can be used as a host General Purpose I/O or a native function.
NOTE: SLP_LAN# may also be configured by Intel
®
ME FW in Sx/Moff. Please refer to SLP_LAN#/
GPIO29 signal description for details.
Table 2-25. Manageability Signals
Name Type Description
SUSWARN# /
SUSPWRDNACK /
GPIO30 (Mobile
Only)
I/O
Used by Intel
®
ME as either SUSWARN# in Deep S4/S5 state
supported platforms or as SUSPWRDNACK in non Deep S4/S5
state supported platforms.
NOTE: This signal is in the Suspend power well.
ACPRESENT /
GPIO31 (Mobile
Only)
I/O
Input signal from the Embedded Controller (EC) on Mobile
systems to indicate AC power source or the system battery.
Active High indicates AC power.
NOTE: This signal is in the Deep S4/S5 power well.
SATA5GP / GPIO49
/ TEMP_ALERT#
I/O
Used as an alert (active low) to indicate to the external
controller (such as EC or SIO) that temperatures are out of
range for the PCH or Graphics/Memory Controller or the
processor core.
NOTE: This signal is in the Core power well.
GPIO24 /
PROC_MISSING
(Desktop Only)
I/O
Used to indicate Processor Missing to the Intel Management
Engine.
NOTE: This signal is in the Suspend power well.
