Datasheet 355
Register and Memory Mapping
9.4 Memory Map
Table 9-4 shows (from the processor perspective) the memory ranges that the PCH
decodes. Cycles that arrive from DMI that are not directed to any of the internal
memory targets that decode directly from DMI will be driven out on PCI unless the
Subtractive Decode Policy bit is set (D31:F0:Offset 42h, bit 0).
PCI cycles generated by external PCI masters will be positively decoded unless they fall
in the PCI-to-PCI bridge memory forwarding ranges (those addresses are reserved for
PCI peer-to-peer traffic). If the cycle is not in the internal LAN controller’s range, it will
be forwarded up to DMI. Software must not attempt locks to the PCH memory-mapped
I/O ranges for EHCI and HPET. If attempted, the lock is not honored which means
potential deadlock conditions may occur.
Table 9-4. Memory Decode Ranges from Processor Perspective (Sheet 1 of 2)
Memory Range Target Dependency/Comments
0000 0000h–000D FFFFh
0010 0000h–TOM
(Top of Memory)
Main Memory TOM registers in Host controller
000E 0000h–000E FFFFh Firmware Hub
Bit 6 in Firmware Hub Decode Enable register
is set
000F 0000h–000F FFFFh Firmware Hub
Bit 7 in Firmware Hub Decode Enable register
is set
FEC_ _000h–FEC_ _040h
IO(x) APIC inside
PCH
_ _is controlled using APIC Range Select
(ASEL) field and APIC Enable (AEN) bit
FEC1 0000h–FEC1 7FFF PCI Express* Port 1
PCI Express* Root Port 1 I/OxAPIC Enable
(PAE) set
FEC1 8000h–FEC1 8FFFh PCI Express* Port 2
PCI Express* Root Port 2 I/OxAPIC Enable
(PAE) set
FEC2 0000h–FEC2 7FFFh PCI Express* Port 3
PCI Express* Root Port 3 I/OxAPIC Enable
(PAE) set
FEC2 8000h–FEC2 8FFFh PCI Express* Port 4
PCI Express* Root Port 4 I/OxAPIC Enable
(PAE) set
FEC3 0000h–FEC3 7FFFh PCI Express* Port 5
PCI Express* Root Port 5 I/OxAPIC Enable
(PAE) set
FEC3 8000h–FEC3 8FFFh PCI Express* Port 6
PCI Express* Root Port 6 I/OxAPIC Enable
(PAE) set
FEC4 0000h–FEC4 7FFF PCI Express* Port 7
PCI Express* Root Port 7I/OxAPIC Enable
(PAE) set
FEC4 8000h–FEC4 FFFF PCI Express* Port 8
PCI Express* Root Port 8I/OxAPIC Enable
(PAE) set
FFC0 0000h–FFC7 FFFFh
FF80 0000h–FF87 FFFFh
Firmware Hub (or
PCI)
2
Bit 8 in Firmware Hub Decode Enable register
is set
FFC8 0000h–FFCF FFFFh
FF88 0000h–FF8F FFFFh
Firmware Hub (or
PCI)
2
Bit 9 in Firmware Hub Decode Enable register
is set
FFD0 0000h–FFD7 FFFFh
FF90 0000h–FF97 FFFFh
Firmware Hub (or
PCI)
2
Bit 10 in Firmware Hub Decode Enable register
is set
FFD8 0000h–FFDF FFFFh
FF98 0000h–FF9F FFFFh
Firmware Hub (or
PCI)
2
Bit 11 in Firmware Hub Decode Enable register
is set
To Next Page
