272 Datasheet
Ballout Definition
Table 6-1. Desktop PCH Ballout By Signal Name
Desktop PCH Ball
Map
Ball #
A20GATE BB57
AD0 BF15
AD1 BF17
AD2 BT7
AD3 BT13
AD4 BG12
AD5 BN11
AD6 BJ12
AD7 BU9
AD8 BR12
AD9 BJ3
AD10 BR9
AD11 BJ10
AD12 BM8
AD13 BF3
AD14 BN2
AD15 BE4
AD16 BE6
AD17 BG15
AD18 BC6
AD19 BT11
AD20 BA14
AD21 BL2
AD22 BC4
AD23 BL4
AD24 BC2
AD25 BM13
AD26 BA9
AD27 BF9
AD28 BA8
AD29 BF8
AD30 AV17
AD31 BK12
APWROK BC46
BATLOW# / GPIO72 AV46
BMBUSY# / GPIO0 AW55
C/BE0# BN4
C/BE1# BP7
C/BE2# BG2
C/BE3# BP13
CL_CLK1 BA50
CL_DATA1 BF50
CL_RST1# BF49
CLKIN_DMI_N P33
CLKIN_DMI_P R33
CLKIN_DOT_96N BD38
CLKIN_DOT_96P BF38
CLKIN_GND0_N W53
CLKIN_GND0_P V52
CLKIN_GND1_N R27
CLKIN_GND1_P P27
CLKIN_PCILOOPBACK BD15
CLKIN_SATA_N AF55
CLKIN_SATA_P AG56
CLKOUT_DMI_N P31
CLKOUT_DMI_P R31
CLKOUT_DP_N N56
CLKOUT_DP_P M55
CLKOUT_ITPXDP_N R52
CLKOUT_ITPXDP_P N52
CLKOUT_PCI0 AT11
CLKOUT_PCI1 AN14
CLKOUT_PCI2 AT12
CLKOUT_PCI3 AT17
CLKOUT_PCI4 AT14
CLKOUT_PCIE0N AE6
CLKOUT_PCIE0P AC6
CLKOUT_PCIE1N AA5
CLKOUT_PCIE1P W5
CLKOUT_PCIE2N AB12
CLKOUT_PCIE2P AB14
CLKOUT_PCIE3N AB9
CLKOUT_PCIE3P AB8
CLKOUT_PCIE4N Y9
CLKOUT_PCIE4P Y8
CLKOUT_PCIE5N AF3
CLKOUT_PCIE5P AG2
CLKOUT_PCIE6N AB3
CLKOUT_PCIE6P AA2
CLKOUT_PCIE7N AE2
CLKOUT_PCIE7P AF1
CLKOUT_PEG_A_N AG8
CLKOUT_PEG_A_P AG9
CLKOUT_PEG_B_N AE12
CLKOUT_PEG_B_P AE11
CLKOUTFLEX0 /
GPIO64
AT9
Desktop PCH Ball
Map
Ball #
CLKOUTFLEX1 /
GPIO65
BA5
CLKOUTFLEX2 /
GPIO66
AW5
CLKOUTFLEX3 /
GPIO67
BA2
CLKRUN# / GPIO32 BC56
CRT_BLUE AM1
CRT_DDC_CLK AW3
CRT_DDC_DATA AW1
CRT_GREEN AN2
CRT_HSYNC AR4
CRT_IRTN AM6
CRT_RED AN6
CRT_VSYNC AR2
DAC_IREF AT3
DcpRTC BR54
DcpRTC_NCTF BT56
DcpSST BA46
DcpSus AA32
DcpSus AT41
DcpSus A39
DcpSusByp AV41
DDPB_0N R12
DDPB_0P R14
DDPB_1N M12
DDPB_1P M11
DDPB_2N K8
DDPB_2P H8
DDPB_3N M3
DDPB_3P L5
DDPB_AUXN R9
DDPB_AUXP R8
DDPB_HPD T1
DDPC_0N J3
DDPC_0P L2
DDPC_1N G4
DDPC_1P G2
DDPC_2N F5
DDPC_2P F3
DDPC_3N E2
DDPC_3P E4
DDPC_AUXN U12
DDPC_AUXP U14
DDPC_CTRLCLK AL12
Desktop PCH Ball
Map
Ball #
