Page #499 background image
Datasheet 499
LPC Interface Bridge Registers (D31:F0)
13.6.2 Indexed Registers
The RTC contains two sets of indexed registers that are accessed using the two
separate Index and Target registers (70/71h or 72/73h), as shown in Table 13-7.
Table 13-7. RTC (Standard) RAM Bank
Index Name
00h Seconds
01h Seconds Alarm
02h Minutes
03h Minutes Alarm
04h Hours
05h Hours Alarm
06h Day of Week
07h Day of Month
08h Month
09h Year
0Ah Register A
0Bh Register B
0Ch Register C
0Dh Register D
0Eh–7Fh 114 Bytes of User RAM
