Intel 6 SERIES CHIPSET - DATASHEET 01-2011 User Manual

Datasheet 309
Electrical Characteristics
Table 8-10. DC Output Characteristics (Sheet 1 of 2)
Symbol Parameter Min Max Unit I
OL /
I
OH
Notes
V
OL1
Output Low Voltage 0 0.255 V 3 mA
V
OH1
Output High Voltage V_PROC_IO - 0.3 V_PROC_IO V
-3 mA
V
OL2
Output Low Voltage — 0.1 × 3.3 V V
1.5 mA
7
V
OH2
Output High Voltage 0.9 × 3.3 V 3.3 V -0.5 mA 7
V
OL3
Output Low Voltage 0 0.4 V 3 mA
V
OH3
Output High Voltage 3.3 V - 0.5 — V 4 mA 1, 7
V
OL4
Output Low Voltage — 0.4 V
6 mA
V
OH4
Output High Voltage 3.3 V - 0.5 3.3 V V
-2 mA
7
V
OL5
Output Low Voltage — 0.4 V
5 mA
V
OH5
Output High Voltage 3.3 V – 0.5 — V -2 mA 7
V
OL6
Output Low Voltage 0 400 mV 3 mA 2
V
OL6 (Fast
Mode)
Output Low Voltage 0 600 mV 6 mA 2
V
OH6
Output High Voltage 3.3 V – 0.5 3.3 V -2 mA 7, 2
V
OMIN7-
Gen1i,m
Minimum Output Voltage 400 —
mVdif
fp-p
3
V
OMAX7-
Gen1i,m
Maximum Output Voltage — 600
mVdif
fp-p
3
V
OMIN7-
Gen2i,m
Minimum Output Voltage 400 —
mVdif
fp-p
3
V
OMAX7-
Gen2i,m
Maximum Output Voltage — 700
mVdif
fp-p
3
V
OMIN8
Output Low Voltage 400 —
mVdif
fp-p
V
OMAX8
Output High Voltage — 600
mVdif
fp-p
V
OL9
Output Low Voltage — 0.1 × 3.3 V V
1.5 mA
7
V
OH9
Output High Voltage 0.9 × 3.3 V 3.3 V -2.0 mA 7
VHSOI HS Idle Level –10.0 10.0 mV
VHSOH
HS Data Signaling High 360 440 mV
VHSOL
HS Data Signaling Low –10.0 10.0 mV
VCHIRPJ
Chirp J Level 700 1100 mV
VCHIRPK
Chirp K Level –900 –500 mV
VOL_HDA
Output Low Voltage — 0.1 × VccSusHDA V
1.5 mA
VOH_HDA
Output High Voltage 0.9 × VccSusHDA — V -0.5 mA
VOL_SGPIO Output Low Voltage — 0.4 V
VOL_CRT
Output Low Voltage — 0.5 V 8 mA
VOH_CRT
Output High Voltage 2.4 — V 8 mA
VOL_CL1
Output Low Voltage — 0.15 V 1 mA
VOH_CL1
Output High Voltage .61 .98 V
VOL_PECI
Output Low Voltage — 0.25 × V_PROC_IO V 0.5 mA
