Electrical Characteristics
308 Datasheet
NOTE:
1. These signals are open-drain.
VHSOI
VHSOH
VHSOL
VCHIRPJ
VCHIRPK
USB Signals: USBP[13:0][P:N] in High-speed Mode
VOH_HDA/
VOL_HDA
Intel
®
High Definition Audio Signals: HDA_RST#, HDA_SDO, HDA_SYNC
VOL_JTAG JTAG Signals: JTAG_TDO
VOH_PCICLK/
VOL_PCICLK
Single Ended Clock Interface Output Signals: CLKOUT_PCI[4:0],
CLKOUTFLEX[3:0]
GPIO Signals: [67:64]
VOL_SGPIO SGPIO Signals: SCLOCK, SLOAD, SDATAOUT0, SDATAOUT1
VOH_CRT/
VOL_CRT
Display Signals: CRT_HSYNC, CRT_VSYNC
VOH_CL1/VOL_CL1
Controller Link Signals: CL_CLK1, CL_DATA1
VAUX-Diff-P-P
Digital Display Port Aux Signal (Transmit Side): DDP[D:B]_AUX[P,N]
VOH_FDI//
VOL_FDI
Intel
®
FDI signals:FDI_FSYNC_[1:0],FDI_LSYNC_[1:0],FDI_INT
VOMIN10 -Gen3i/
VOMAX10-Gen3i
SATA Signals: SATA[5:0]RX[P,N] (6.0 Gb/s Internal SATA)
V
OMIN11-
PCIeGen12
V
OMAX11-
PCIeGen12
PCI Express* Data TX Signals: PET[p,n][8:1] (Gen1 and Gen2)
Table 8-9. DC Characteristic Output Signal Association (Sheet 2 of 2)
Symbol Associated Signals
