Integrated Intel
®
High Definition Audio Controller Registers
706 Datasheet
17.1.2 Intel
®
High Definition Audio Memory Mapped
Configuration Registers
(Intel
®
High Definition Audio D27:F0)
The base memory location for these memory mapped configuration registers is
specified in the HDBAR register (D27:F0:offset 10h and D27:F0:offset 14h). The
individual registers are then accessible at HDBAR + Offset as indicated in Table 17-2.
These memory mapped registers must be accessed in byte, word, or DWord quantities.
Table 17-2. Intel
®
High Definition Audio Memory Mapped Configuration Registers
Address Map (Intel
®
High Definition Audio D27:F0) (Sheet 1 of 4)
HDBAR +
Offset
Mnemonic Register Name Default Access
00h–01h GCAP Global Capabilities 4401h RO, R/WO
02h VMIN Minor Version 00h RO
03h VMAJ Major Version 01h RO
04h–05h OUTPAY Output Payload Capability 003Ch RO
06h–07h INPAY Input Payload Capability 001Dh RO
08h–0Bh GCTL Global Control 00000000h R/W
0Ch–0Dh WAKEEN Wake Enable 0000h R/W
0Eh–0Fh STATESTS State Change Status 0000h R/WC
10h–11h GSTS Global Status 0000h R/WC
12h–13h Rsv Reserved 0000h RO
14h–17h Rsv Reserved 00000000h RO
18h–19h OUTSTRMPAY Output Stream Payload Capability 0030h RO
1Ah–1Bh INSTRMPAY Input Stream Payload Capability 0018h RO
1Ch–1Fh Rsv Reserved 00000000h RO
20h–23h INTCTL Interrupt Control 00000000h R/W
24h–27h INTSTS Interrupt Status 00000000h RO
30h–33h WALCLK Wall Clock Counter 00000000h RO
34–37h Rsv Reserved 00000000h RO
38h–3Bh SSYNC Stream Synchronization 00000000h R/W
40h–43h CORBLBASE CORB Lower Base Address 00000000h R/W, RO
44h–47h CORBUBASE CORB Upper Base Address 00000000h R/W
48h–49h CORBWP CORB Write Pointer 0000h R/W
4Ah–4Bh CORBRP CORB Read Pointer 0000h R/W, RO
4Ch CORBCTL CORB Control 00h R/W
4Dh CORBST CORB Status 00h R/WC
4Eh CORBSIZE CORB Size 42h RO
50h–53h RIRBLBASE RIRB Lower Base Address 00000000h R/W, RO
54h–57h RIRBUBASE RIRB Upper Base Address 00000000h R/W
58h–59h RIRBWP RIRB Write Pointer 0000h R/W, RO
