Intel 6 SERIES CHIPSET - DATASHEET 01-2011 - DC Input Characteristics

Electrical Characteristics
304 Datasheet
Table 8-8. DC Input Characteristics (Sheet 1 of 3)
Symbol Parameter Min Max Unit Notes
VIL1 Input Low Voltage –0.5 0.3 × 3.3 V V 10
VIH1 Input High Voltage 0.5 × 3.3 V V5REF + 0.5 V 10
VIL2 Input Low Voltage — .8 V
VIH2 Input High Voltage 2 — V
VIL3 Input Low Voltage –0.5 0.8 V
VIH3 Input High Voltage 2.0 3.3 V + 0.5 V 10
VIL4 Input Low Voltage –0.5 0.3 × 3.3 V V 10
VIH4 Input High Voltage 0.5 × 3.3 V 3.3 V + 0.5 V 10
VIL5 Input Low Voltage 0 0.8 V
VIH5 Input High Voltage 2.1 3.3 V + 0.5 V 10
VIL6 Input Low Voltage -0.5 0.35 V 11
VIH6 Input High Voltage 0.75 1.05 V + 0.5 V 11
VIL7 Input Low Voltage 0 0.25 × V_PROC_IO V
VIH7 Input High Voltage 0.75 × V_PROC_IO V_PROC_IO V
VIMIN8Gen1 Minimum Input Voltage 175 — mVdiffp-p 4
VIMAX8Gen1 Maximum Input Voltage — 1200 mVdiffp-p 4
VIMIN8Gen2 Minimum Input Voltage 100 — mVdiffp-p 4
VIMAX8Gen2 Maximum Input Voltage — 1200 mVdiffp-p 4
VIL9 Input Low Voltage –0.5 0.10 V
VIH9 Input High Voltage 0.50 1.2 V
VIMIN10-
Gen1i
Minimum Input Voltage -
1.5 Gb/s internal SATA
325 — mVdiffp-p 5
VIMAX10-
Gen1i
Maximum Input Voltage -
1.5 Gb/s internal SATA
— 600 mVdiffp-p 5
VIMIN10-
Gen1m
Minimum Input Voltage -
1.5 Gb/s eSATA
240 — mVdiffp-p 5
VIMAX10-
Gen1m
Maximum Input Voltage -
1.5 Gb/s eSATA
— 600 mVdiffp-p 5
VIMIN10-
Gen2i
Minimum Input Voltage -
3.0 Gb/s internal SATA
275 — mVdiffp-p 5
VIMAX10-
Gen2i
Maximum Input Voltage -
3.0 Gb/s internal SATA
— 750 mVdiffp-p 5
VIMIN10-
Gen2m
Minimum Input Voltage -
3.0 Gb/s eSATA
240 — mVdiffp-p 5
VIMAX10-
Gen2m
Maximum Input Voltage -
3.0 Gb/s eSATA
— 750 mVdiffp-p 5
VIL11 Input Low Voltage
0
0.35 × 3.3 V V 10
VIH11 Input High Voltage 0.65 × 3.3 V 3.3 + 0.5V V 10
