Intel 6 SERIES CHIPSET - DATASHEET 01-2011 - Port Connectivity; Location

Datasheet 735
Integrated Intel
®
High Definition Audio Controller Registers
Table 17-5. Port Connectivity
Value Value
00b The Port Complex is connected to a jack
01b No physical connection for port
10b A fixed function device (integrated speaker, integrated mic etc) is attached
11b Both a jack and an internal device attached
Table 17-6. Location
Bits 5:4
00b
External of
Primary
Chassis
01b
Internal
10b
Separate
Chassis
11b
Other
Bits 3:0
0h XXXX
1h:Rear XX
2h:Front XX
3h:Left XX
4h:Right XX
5h:Top XX
6h:Bottom XXX
7h:Special X (Rear Panel) X (Riser)
X (Mobile Lid-
Inside)
8h:Special X (Drive bay)
X (Digital
Display)
X (Mobile Lid-
Outside)
9h:Special X (ATAPI)
Ah-Fh:Reserved
