Integrated Intel
®
High Definition Audio Controller Registers
736 Datasheet
Table 17-7. Default Device
Default Device Encoding
Line Out 0h
Speaker 1h
HP Out 2h
CD 3h
S/PDIF* Out 4h
Digital Other Side 5h
Modem Line side 6h
Modem Hand Set Side 7h
Line In 8h
AUX 9h
Mic In Ah
Telephony Bh
S/PDIF In Ch
Digital Other In Dh
Reserved Eh
Other Fh
Table 17-8. Connection Type
Connection Type Encoding
Unknown 0h
1/8” Stereo/Mono 1h
1/4” Stereo/Mono 2h
ATAPI Internal 3h
RCA 4h
Optical 5h
Other Digital 6h
Other Analog 7h
Multichannel Analog (DIN) 8h
XLR/Professional 9h
RJ-11 (modem) Ah
Combination Bh
Other Fh
