Electrical Characteristics

346 Datasheet

Figure 8-29. PCI Express Receiver Eye

V

RS-Diffp-p-Min>175mV

.4 UI =T

RX-EYE min

V

TS-Diff = 0mV

D+/D- Crossing point
