High Definition Audio Controller Registers
Config Default register needs to be programmed in BIOS to enable or disable the audio
on the port. More details of the register and other audio registers’ programming can be
found in High Definition Audio Specification 1.0a at www.intel.com/standards.
§ §
Table 17-9. Color
Color Encoding
Unknown 0h
Black 1h
Grey 2h
Blue 3h
Green 4h
Red 5h
Orange 6h
Yellow 7h
Purple 8h
Pink 9h
Reserved A–Dh
White Eh
Other Fh
Table 17-10. Misc
Misc Bit
Reserved 3
Reserved 2
Reserved 1
