Functional Description
262 Datasheet
5.26.3 Mapping of Digital Display Interface Signals
Table 5-60. PCH Digital Port Pin Mapping
Port
Description
DisplayPort*
Signals
HDMI* Signals SDVO Signals
PCH Display
Port Pin details
Port B
DPB_LANE3 TMDSB_CLK SDVOB_CLK DDPB_[3]P
DPB_LANE3# TMDSB_CLKB SDVOB_CLK# DDPB_[3]N
DPB_LANE2 TMDSB_DATA0 SDVOB_BLUE DDPB_[2]P
DPB_LANE2# TMDSB_DATA0B SDVOB_BLUE# DDPB_[2]N
DPB_LANE1 TMDSB_DATA1 SDVOB_GREEN DDPB_[1]P
DPB_LANE1# TMDSB_DATA1B SDVOB_GREEN# DDPB_[1]N
DPB_LANE0 TMDSB_DATA2 SDVOB_RED DDPB_[0]P
DPB_LANE0# TMDSB_DATA2B SDVOB_RED* DDPB_[0]N
DPB_HPD TMDSB_HPD DDPB_HPD
DPB_AUX
DDPB_AUXP
DPB_AUXB
DDPB_AUXN
Port C
DPC_LANE3 TMDSC_CLK DDPC_[3]P
DPC_LANE3# TMDSC_CLKB DDPC_[3]N
DPC_LANE2 TMDSC_DATA0 DDPC_[2]P
DPC_LANE2# TMDSC_DATA0B DDPC_[2]N
DPC_LANE1 TMDSC_DATA1 DDPC_[1]P
DPC_LANE1# TMDSC_DATA1B DDPC_[1]N
DPC_LANE0 TMDSC_DATA2 DDPC_[0]P
DPC_LANE0# TMDSC_DATA2B DDPC_[0]N
DPC_HPD TMDSC_HPD DDPC_HPD
DPC_AUX
DDPC_AUXP
DPC_AUXC DDPC_AUXN
Port D
DPD_LANE3 TMDSD_CLK DDPD_[3]P
DPD_LANE3# TMDSD_CLKB DDPD_[3]N
DPD_LANE2 TMDSD_DATA0 DDPD_[2]P
DPD_LANE2# TMDSD_DATA0B DDPD_[2]N
DPD_LANE1 TMDSD_DATA1 DDPD_[1]P
DPD_LANE1# TMDSD_DATA1B DDPD_[1]N
DPD_LANE0 TMDSD_DATA2 DDPD_[0]P
DPD_LANE0# TMDSD_DATA2B DDPD_[0]N
DPD_HPD TMDSD_HPD DDPD_HPD
DPD_AUX
DDPD_AUXP
DPD_AUXD DDPD_AUXN
