Datasheet 273
Ballout Definition
DDPC_CTRLDATA AL14
DDPC_HPD N2
DDPD_0N B5
DDPD_0P D5
DDPD_1N D7
DDPD_1P C6
DDPD_2N C9
DDPD_2P B7
DDPD_3N B11
DDPD_3P E11
DDPD_AUXN R6
DDPD_AUXP N6
DDPD_CTRLCLK AL9
DDPD_CTRLDATA AL8
DDPD_HPD M1
DEVSEL# BH9
DMI_IRCOMP B31
DMI_ZCOMP E31
DMI0RXN D33
DMI0RXP B33
DMI0TXN J36
DMI0TXP H36
DMI1RXN A36
DMI1RXP B35
DMI1TXN P38
DMI1TXP R38
DMI2RBIAS A32
DMI2RXN B37
DMI2RXP C36
DMI2TXN H38
DMI2TXP J38
DMI3RXN E37
DMI3RXP F38
DMI3TXN M41
DMI3TXP P41
DPWROK BT37
DRAMPWROK BG46
DSWVRMEN BR42
FDI_FSYNC0 B51
FDI_FSYNC1 C52
FDI_INT H46
FDI_LSYNC0 E49
FDI_LSYNC1 D51
FDI_RXN0 C42
FDI_RXN1 F45
FDI_RXN2 H41
Desktop PCH Ball
Map
Ball #
FDI_RXN3 C46
FDI_RXN4 B45
FDI_RXN5 B47
FDI_RXN6 J43
FDI_RXN7 M43
FDI_RXP0 B43
FDI_RXP1 F43
FDI_RXP2 J41
FDI_RXP3 D47
FDI_RXP4 A46
FDI_RXP5 C49
FDI_RXP6 H43
FDI_RXP7 P43
FRAME# BC11
FWH0 / LAD0 BK15
FWH1 / LAD1 BJ17
FWH2 / LAD2 BJ20
FWH3 / LAD3 BG20
FWH4 / LFRAME# BG17
GNT0# BA15
GNT1# / GPIO51 AV8
GNT2# / GPIO53 BU12
GNT3# / GPIO55 BE2
GPIO15 BM55
GPIO24 /
PROC_MISSING
BP53
GPIO27 BJ43
GPIO28 BJ55
GPIO31 BG43
GPIO35 BJ57
GPIO57 BT53
GPIO8 BP51
HDA_BCLK BU22
HDA_DOCK_EN# /
GPIO33
BC25
HDA_DOCK_RST# /
GPIO13
BA25
HDA_RST# BC22
HDA_SDIN0 BD22
HDA_SDIN1 BF22
HDA_SDIN2 BK22
HDA_SDIN3 BJ22
HDA_SDO BT23
HDA_SYNC BP23
INIT3_3V# BN56
INTRUDER# BM38
INTVRMEN BN41
Desktop PCH Ball
Map
Ball #
IRDY# BF11
JTAG_TCK BA43
JTAG_TDI BC52
JTAG_TDO BF47
JTAG_TMS BC50
L_BKLTCTL AG12
L_BKLTEN AG18
L_VDD_EN AG17
LAN_PHY_PWR_CTRL /
GPIO12
BK50
LDRQ0# BK17
LDRQ1# / GPIO23 BA20
TS_VSS1 A54
TS_VSS2 A52
TS_VSS3 F57
TS_VSS4 D57
NC_1 AY20
Reserved M48
Reserved K50
Reserved K49
Reserved AB46
Reserved G56
DF_TVS R47
Reserved AB50
Reserved Y50
Reserved AB49
Reserved AB44
Reserved U49
Reserved R44
Reserved U50
Reserved U46
Reserved U44
Reserved H50
Reserved K46
Reserved L56
Reserved J55
Reserved F53
Reserved H52
Reserved E52
Reserved Y44
Reserved L53
Reserved Y41
Reserved R50
Reserved M50
Reserved M49
Reserved U43
Reserved J57
Desktop PCH Ball
Map
Ball #
