Intel 6 SERIES CHIPSET - DATASHEET 01-2011

274 Datasheet
Ballout Definition
OC0# / GPIO59 BM43
OC1# / GPIO40 BD41
OC2# / GPIO41 BG41
OC3# / GPIO42 BK43
OC4# / GPIO43 BP43
OC5# / GPIO9 BJ41
OC6# / GPIO10 BT45
OC7# / GPIO14 BM45
PAR BH8
PCIECLKRQ2# /
GPIO20
AV43
PCIECLKRQ5# /
GPIO44
BL54
PCIECLKRQ6# /
GPIO45
AV44
PCIECLKRQ7# /
GPIO46
BP55
PCIRST# AV14
PECI H48
PERn1 J20
PERn2 P20
PERn3 H17
PERn4 P17
PERn5 N15
PERn6 J15
PERn7 J12
PERn8 H10
PERp1 L20
PERp2 R20
PERp3 J17
PERp4 M17
PERp5 M15
PERp6 L15
PERp7 H12
PERp8 J10
PERR# BM3
PETn1 F25
PETn2 C22
PETn3 E21
PETn4 F18
PETn5 B17
PETn6 A16
PETn7 F15
PETn8 B13
PETp1 F23
PETp2 A22
PETp3 B21
PETp4 E17
Desktop PCH Ball
Map
Ball #
PETp5 C16
PETp6 B15
PETp7 F13
PETp8 D13
PIRQA# BK10
PIRQB# BJ5
PIRQC# BM15
PIRQD# BP5
PIRQE# / GPIO2 BN9
PIRQF# / GPIO3 AV9
PIRQG# / GPIO4 BT15
PIRQH# / GPIO5 BR4
PLOCK# BA17
PLTRST# BK48
PME# AV15
PMSYNCH F55
PROCPWRGD D53
RSVD BN21
RSVD BT21
RSVD BM20
RSVD BN19
PWRBTN# BT43
PWROK BJ38
RCIN# BG56
REFCLK14IN AN8
REQ0# BG5
REQ1# / GPIO50 BT5
REQ2# / GPIO52 BK8
REQ3# / GPIO54 AV11
RI# BJ48
RSMRST# BK38
RTCRST# BT41
RTCX1 BR39
RTCX2 BN39
SATA0GP / GPIO21 BC54
SATA0RXN AC56
SATA0RXP AB55
SATA0TXN AE46
SATA0TXP AE44
SATA1GP / GPIO19 AY52
SATA1RXN AA53
SATA1RXP AA56
SATA1TXN AG49
SATA1TXP AG47
SATA2GP / GPIO36 BB55
SATA2RXN AL50
Desktop PCH Ball
Map
Ball #
SATA2RXP AL49
SATA2TXN AL56
SATA2TXP AL53
SATA3COMPI AE54
SATA3GP / GPIO37 BG53
SATA3RBIAS AC52
SATA3RCOMPO AE52
SATA3RXN AN46
SATA3RXP AN44
SATA3TXN AN56
SATA3TXP AM55
SATA4GP / GPIO16 AU56
SATA4RXN AN49
SATA4RXP AN50
SATA4TXN AT50
SATA4TXP AT49
SATA5GP / GPIO49 /
THERM_ALERT#
BA56
SATA5RXN AT46
SATA5RXP AT44
SATA5TXN AV50
SATA5TXP AV49
SATAICOMPI AJ55
SATAICOMPO AJ53
SATALED# BF57
SCLOCK / GPIO22 BA53
SDATAOUT0 / GPIO39 BF55
SDATAOUT1 / GPIO48 AW53
SDVO_CTRLCLK AL15
SDVO_CTRLDATA AL17
SDVO_INTN T3
SDVO_INTP U2
SDVO_STALLN U5
SDVO_STALLP W3
SDVO_TVCLKINN U9
SDVO_TVCLKINP U8
SERIRQ AV52
SERR# BR6
SLOAD / GPIO38 BE54
SLP_A# BC41
SLP_LAN# / GPIO29 BH49
SLP_S3# BM53
SLP_S4# BN52
SLP_S5# / GPIO63 BH50
SLP_SUS# BD43
SMBALERT# / GPIO11 BN49
SMBCLK BT47
Desktop PCH Ball
Map
Ball #
