SMBDATA BR49
SML0ALERT# /
GPIO60
BU49
SML0CLK BT51
SML0DATA BM50
SML1ALERT# /
PCHHOT# / GPIO74
BR46
SML1CLK / GPIO58 BJ46
SML1DATA / GPIO75 BK46
SPI_CLK AR54
SPI_CS0# AT57
SPI_CS1# AR56
SPI_MISO AT55
SPI_MOSI AU53
SPKR BE56
SRTCRST# BN37
RSVD BC43
STOP# BC12
STP_PCI# / GPIO34 BL56
SUS_STAT# / GPIO61 BN54
SUSACK# BP45
SUSCLK / GPIO62 BA47
SUSWARN#/
SUSPWRDNACK/
GPIO30
BU46
SYS_PWROK BJ53
SYS_RESET# BE52
GPIO17 BT17
GPIO1 BR19
GPIO6 BA22
GPIO7 BR16
GPIO68 BU16
GPIO69 BM18
GPIO70 BN17
GPIO71 BP15
THRMTRIP# E56
TP1 P22
TP2 L31
TP3 L33
TP4 M38
TP5 L36
TP6 Y18
TP7 Y17
TP8 AB18
TP9 AB17
TP10 BM46
TP11 BA27
TP12 BC49
Desktop PCH Ball
Map
Ball #
TP13 AE49
TP14 AE41
TP15 AE43
TP16 AE50
TP17 BA36
TP18 AY36
TP19 Y14
TP20 Y12
TP21 H31
TP22 J27
TP23 J25
TP24 L22
TP25 J31
TP26 L27
TP27 L25
TP28 J22
TP29 C29
TP30 F28
TP31 C26
TP32 B25
TP33 E29
TP34 E27
TP35 B27
TP36 D25
TRDY# BC8
USBP0N BF36
USBP0P BD36
USBP1N BC33
USBP1P BA33
USBP2N BM33
USBP2P BM35
USBP3N BT33
USBP3P BU32
USBP4N BR32
USBP4P BT31
USBP5N BN29
USBP5P BM30
USBP6N BK33
USBP6P BJ33
USBP7N BF31
USBP7P BD31
USBP8N BN27
USBP8P BR29
USBP9N BR26
USBP9P BT27
USBP10N BK25
Desktop PCH Ball
Map
Ball #
USBP10P BJ25
USBP11N BJ31
USBP11P BK31
USBP12N BF27
USBP12P BD27
USBP13N BJ27
USBP13P BK27
USBRBIAS BM25
USBRBIAS# BP25
V_PROC_IO D55
V_PROC_IO_NCTF B56
V5REF BF1
V5REF_Sus BT25
Vcc3_3 AF57
Vcc3_3 BC17
Vcc3_3 BD17
Vcc3_3 BD20
Vcc3_3 AL38
Vcc3_3 AN38
Vcc3_3 AU22
Vcc3_3 A12
Vcc3_3 AU20
Vcc3_3 AV20
VccAClk AL5
VccADAC AT1
VccADPLLA AB1
VccADPLLB AC2
VccAFDIPLL C54
VccAPLLDMI2 A19
VccAPLLEXP B53
VccAPLLSATA U56
VccASW AU32
VccASW AV36
VccASW AU34
VccASW AG24
VccASW AG26
VccASW AG28
VccASW AJ24
VccASW AJ26
VccASW AJ28
VccASW AL24
VccASW AL28
VccASW AN22
VccASW AN24
VccASW AN26
