Ballout Definition
VccASW AN28
VccASW AR24
VccASW AR26
VccASW AR28
VccASW AR30
VccASW AR36
VccASW AR38
VccASW AU30
VccASW AU36
VccClkDMI AJ20
VccCore AC24
VccCore AC26
VccCore AC28
VccCore AC30
VccCore AC32
VccCore AE24
VccCore AE28
VccCore AE30
VccCore AE32
VccCore AE34
VccCore AE36
VccCore AG32
VccCore AG34
VccCore AJ32
VccCore AJ34
VccCore AJ36
VccCore AL32
VccCore AL34
VccCore AN32
VccCore AN34
VccCore AR32
VccCore AR34
VccDIFFCLKN AE15
VccDIFFCLKN AE17
VccDIFFCLKN AG15
VccDMI E41
VccDMI B41
VccDSW3_3 AV40
VccIO AV24
VccIO AV26
VccIO AY25
VccIO AY27
VccIO AG41
VccIO AL40
VccIO AN40
VccIO AN41
Desktop PCH Ball
Map
Ball #
VccIO AJ38
VccIO Y36
VccIO V36
VccIO Y28
VccIO AE40
VccIO BA38
VccIO AG38
VccIO AG40
VccIO AA34
VccIO AA36
VccIO F20
VccIO F30
VccIO V25
VccIO V27
VccIO V31
VccIO V33
VccIO Y24
VccIO Y26
VccIO Y30
VccIO Y32
VccIO Y34
VccIO V22
VccIO Y20
VccIO Y22
VccDFTERM T55
VccDFTERM T57
VccRTC BU42
VccSPI AN52
VccSSC AC20
VccSSC AE20
VccSus3_3 U31
VccSus3_3 AV30
VccSus3_3 AV32
VccSus3_3 AY31
VccSus3_3 AY33
VccSus3_3 BJ36
VccSus3_3 BK36
VccSus3_3 BM36
VccSus3_3 AT40
VccSus3_3 AU38
VccSus3_3 BT35
VccSusHDA AV28
VccVRM AJ1
VccVRM R56
VccVRM R54
VccVRM R2
Desktop PCH Ball
Map
Ball #
Vss AE56
Vss BR36
Vss C12
Vss AY22
Vss A26
Vss A29
Vss A42
Vss A49
Vss A9
Vss AA20
Vss AA22
Vss AA24
Vss AA26
Vss AA28
Vss AA30
Vss AA38
Vss AB11
Vss AB15
Vss AB40
Vss AB41
Vss AB43
Vss AB47
Vss AB52
Vss AB57
Vss AB6
Vss AC22
Vss AC34
Vss AC36
Vss AC38
Vss AC4
Vss AC54
Vss AE14
Vss AE18
Vss AE22
Vss AE26
Vss AE38
Vss AE4
Vss AE47
Vss AE8
Vss AE9
Vss AF52
Vss AF6
Vss AG11
Vss AG14
Vss AG20
Vss AG22
