Register and Memory Mapping
356 Datasheet
NOTES:
1. Software must not attempt locks to memory mapped I/O ranges for USB EHCI or High
Precision Event Timers. If attempted, the lock is not honored, which means potential
deadlock conditions may occur.
2. PCI is the target when the Boot BIOS Destination selection bits are set to 10b (Chipset
Config Registers:Offset 3401 bits 11:10). When PCI selected, the Firmware Hub Decode
Enable bits have no effect.
FFE0 000h–FFE7 FFFFh
FFA0 0000h–FFA7 FFFFh
Firmware Hub (or
PCI)
2
Bit 12 in Firmware Hub Decode Enable register
is set
FFE8 0000h–FFEF FFFFh
FFA8 0000h–FFAF FFFFh
Firmware Hub (or
PCI)
3
Bit 13 in Firmware Hub Decode Enable register
is set
FFF0 0000h–FFF7 FFFFh
FFB0 0000h–FFB7 FFFFh
Firmware Hub (or
PCI)
2
Bit 14 in Firmware Hub Decode Enable register
is set
FFF8 0000h–FFFF FFFFh
FFB8 0000h–FFBF FFFFh
Firmware Hub (or
PCI)
2
Always enabled.
The top two, 64 KB blocks of this range can be
swapped, as described in Section 7.4.1.
FF70 0000h–FF7F FFFFh
FF30 0000h–FF3F FFFFh
Firmware Hub (or
PCI)
2
Bit 3 in Firmware Hub Decode Enable register
is set
FF60 0000h–FF6F FFFFh
FF20 0000h–FF2F FFFFh
Firmware Hub (or
PCI)
2
Bit 2 in Firmware Hub Decode Enable register
is set
FF50 0000h–FF5F FFFFh
FF10 0000h–FF1F FFFFh
Firmware Hub (or
PCI)
2
Bit 1 in Firmware Hub Decode Enable register
is set
FF40 0000h–FF4F FFFFh
FF00 0000h–FF0F FFFFh
Firmware Hub (or
PCI)
2
Bit 0 in Firmware Hub Decode Enable register
is set
128 KB anywhere in 4-GB
range
Integrated LAN
Controller
Enable using BAR in Device 25:Function 0
(Integrated LAN Controller)
1 KB anywhere in 4-GB
range
USB EHCI
Controller #1
1
Enable using standard PCI mechanism (Device
29, Function 0/7)
1 KB anywhere in 4-GB
range
USB EHCI
Controller #2
1
Enable using standard PCI mechanism (Device
26, Function 0/7)
16 KB anywhere in 64-bit
addressing space
Intel
®
High
Definition Audio
Host Controller
Enable using standard PCI mechanism (Device
27, Function 0)
FED0 X000h–FED0 X3FFh
High Precision
Event Timers
1
BIOS determines the “fixed” location which is
one of four, 1-KB ranges where X (in the first
column) is 0h, 1h, 2h, or 3h.
All other PCI None
Table 9-4. Memory Decode Ranges from Processor Perspective (Sheet 2 of 2)
Memory Range Target Dependency/Comments
