Intel 6 SERIES CHIPSET - DATASHEET 01-2011

Datasheet 285
Ballout Definition
DRAMPWROK B13
DSWVRMEN A18
FDI_FSYNC0 AV12
FDI_FSYNC1 BC10
FDI_INT AW16
FDI_LSYNC0 AV14
FDI_LSYNC1 BB10
FDI_RXN0 BJ14
FDI_RXN1 AY14
FDI_RXN2 BE14
FDI_RXN3 BH13
FDI_RXN4 BC12
FDI_RXN5 BJ12
FDI_RXN6 BG10
FDI_RXN7 BG9
FDI_RXP0 BG14
FDI_RXP1 BB14
FDI_RXP2 BF14
FDI_RXP3 BG13
FDI_RXP4 BE12
FDI_RXP5 BG12
FDI_RXP6 BJ10
FDI_RXP7 BH9
FWH0 / LAD0 C38
FWH1 / LAD1 A38
FWH2 / LAD2 B37
FWH3 / LAD3 C37
FWH4 / LFRAME# D36
GNT1# / GPIO51 D47
GNT2# / GPIO53 E42
GNT3# / GPIO55 F46
GPIO15 G2
GPIO24 E8
GPIO27 E16
GPIO28 P8
GPIO35 K4
GPIO57 D6
GPIO8 C10
HDA_BCLK N34
HDA_DOCK_EN# /
GPIO33
C36
HDA_DOCK_RST# /
GPIO13
N32
HDA_RST# K34
HDA_SDIN0 E34
HDA_SDIN1 G34
Mobile PCH Ball
Name
Ball #
HDA_SDIN2 C34
HDA_SDIN3 A34
HDA_SDO A36
HDA_SYNC L34
INIT3_3V# T14
INTRUDER# K22
INTVRMEN C17
JTAG_TCK J3
JTAG_TDI K5
JTAG_TDO H1
JTAG_TMS H7
L_BKLTCTL P45
L_BKLTEN J47
L_CTRL_CLK T45
L_CTRL_DATA P39
L_DDC_CLK T40
L_DDC_DATA K47
L_VDD_EN M45
LAN_PHY_PWR_CTR
L / GPIO12
C4
LDRQ0# E36
LDRQ1# / GPIO23 K36
LVD_IBG AF37
LVD_VBG AF36
LVD_VREFH AE48
LVD_VREFL AE47
LVDSA_CLK AK40
LVDSA_CLK# AK39
LVDSA_DATA#0 AN48
LVDSA_DATA#1 AM47
LVDSA_DATA#2 AK47
LVDSA_DATA#3 AJ48
LVDSA_DATA0 AN47
LVDSA_DATA1 AM49
LVDSA_DATA2 AK49
LVDSA_DATA3 AJ47
LVDSB_CLK AF39
LVDSB_CLK# AF40
LVDSB_DATA#0 AH45
LVDSB_DATA#1 AH47
LVDSB_DATA#2 AF49
LVDSB_DATA#3 AF45
LVDSB_DATA0 AH43
LVDSB_DATA1 AH49
LVDSB_DATA2 AF47
LVDSB_DATA3 AF43
Mobile PCH Ball
Name
Ball #
TS_VSS1 AH8
TS_VSS2 AK11
TS_VSS3 AH10
TS_VSS4 AK10
NC_1 P37
Reserved AV5
Reserved AY7
Reserved AV7
Reserved AU3
Reserved BG4
DF_TVS AY1
Reserved AU2
Reserved AT4
Reserved BB5
Reserved BB3
Reserved BB7
Reserved BE8
Reserved BD4
Reserved BF6
Reserved AT3
Reserved AT1
Reserved AY3
Reserved AT5
Reserved AV3
Reserved AV1
Reserved BB1
Reserved BA3
Reserved AT10
Reserved BC8
Reserved AT8
Reserved AV10
Reserved AY5
Reserved BA2
Reserved AT12
Reserved BF3
OC0# / GPIO59 A14
OC1# / GPIO40 K20
OC2# / GPIO41 B17
OC3# / GPIO42 C16
OC4# / GPIO43 L16
OC5# / GPIO9 A16
OC6# / GPIO10 D14
OC7# / GPIO14 C14
PCIECLKRQ0# /
GPIO73
J2
Mobile PCH Ball
Name
Ball #
