Intel 6 SERIES CHIPSET - DATASHEET 01-2011

286 Datasheet
Ballout Definition
PCIECLKRQ1# /
GPIO18
M1
PCIECLKRQ2# /
GPIO20
V10
PCIECLKRQ3# /
GPIO25
A8
PCIECLKRQ4# /
GPIO26
L12
PCIECLKRQ5# /
GPIO44
L14
PCIECLKRQ6# /
GPIO45
T13
PCIECLKRQ7# /
GPIO46
K12
PECI AU16
PEG_A_CLKRQ# /
GPIO47
M10
PEG_B_CLKRQ# /
GPIO56
E6
PERn1 BG34
PERn2 BE34
PERn3 BG36
PERn4 BF36
PERn5 BG37
PERn6 BJ38
PERn7 BG40
PERn8 BE38
PERp1 BJ34
PERp2 BF34
PERp3 BJ36
PERp4 BE36
PERp5 BH37
PERp6 BG38
PERp7 BJ40
PERp8 BC38
PETn1 AV32
PETn2 BB32
PETn3 AV34
PETn4 AY34
PETn5 AY36
PETn6 AU36
PETn7 AY40
PETn8 AW38
PETp1 AU32
PETp2 AY32
PETp3 AU34
PETp4 BB34
PETp5 BB36
PETp6 AV36
Mobile PCH Ball
Name
Ball #
PETp7 BB40
PETp8 AY38
PIRQA# K40
PIRQB# K38
PIRQC# H38
PIRQD# G38
PIRQE# / GPIO2 G42
PIRQF# / GPIO3 G40
PIRQG# / GPIO4 C42
PIRQH# / GPIO5 D44
PLTRST# C6
PME# K10
PMSYNCH AP14
PROCPWRGD AY11
PWRBTN# E20
PWROK L22
RCIN# P5
REFCLK14IN K45
REQ1# / GPIO50 C46
REQ2# / GPIO52 C44
REQ3# / GPIO54 E40
RI# A10
RSMRST# C21
RTCRST# D20
RTCX1 A20
RTCX2 C20
SATA0GP / GPIO21 V14
SATA0RXN AM3
SATA0RXP AM1
SATA0TXN AP7
SATA0TXP AP5
SATA1GP / GPIO19 P1
SATA1RXN AM10
SATA1RXP AM8
SATA1TXN AP11
SATA1TXP AP10
SATA2GP / GPIO36 V8
SATA2RXN AD7
SATA2RXP AD5
SATA2TXN AH5
SATA2TXP AH4
SATA3COMPI AB13
SATA3GP / GPIO37 M5
SATA3RBIAS AH1
SATA3RCOMPO AB12
SATA3RXN AB8
Mobile PCH Ball
Name
Ball #
SATA3RXP AB10
SATA3TXN AF3
SATA3TXP AF1
SATA4GP / GPIO16 U2
SATA4RXN Y7
SATA4RXP Y5
SATA4TXN AD3
SATA4TXP AD1
SATA5GP / GPIO49/
THERM_ALERT#
V3
SATA5RXN Y3
SATA5RXP Y1
SATA5TXN AB3
SATA5TXP AB1
SATAICOMPI Y10
SATAICOMPO Y11
SATALED# P3
SCLOCK / GPIO22 T5
SDATAOUT0 /
GPIO39
M3
SDATAOUT1 /
GPIO48
V13
SDVO_CTRLCLK P38
SDVO_CTRLDATA M39
SDVO_INTN AP39
SDVO_INTP AP40
SDVO_STALLN AM42
SDVO_STALLP AM40
SDVO_TVCLKINN AP43
SDVO_TVCLKINP AP45
SERIRQ V5
SLOAD / GPIO38 N2
SLP_A# G10
SLP_LAN# / GPIO29 K14
SLP_S3# F4
SLP_S4# H4
SLP_S5# / GPIO63 D10
SLP_SUS# G16
SMBALERT# /
GPIO11
E12
SMBCLK H14
SMBDATA C9
SML0ALERT# /
GPIO60
A12
SML0CLK C8
SML0DATA G12
SML1ALERT# /
PCHHOT# / GPIO74
C13
Mobile PCH Ball
Name
Ball #
