Ballout Definition
SML1CLK / GPIO58 E14
SML1DATA / GPIO75 M16
SPI_CLK T3
SPI_CS0# Y14
SPI_CS1# T1
SPI_MISO U3
SPI_MOSI V4
SPKR T10
SRTCRST# G22
STP_PCI# / GPIO34 K1
SUS_STAT# /
GPIO61
G8
SUSACK# C12
SUSCLK / GPIO62 N14
SUSWARN#/
SUSPWRDNACK/
GPIO30
K16
SYS_PWROK P12
SYS_RESET# K3
GPIO17 D40
GPIO1 A42
GPIO6 H36
GPIO7 E38
GPIO68 C40
GPIO69 B41
GPIO70 C41
GPIO71 A40
THRMTRIP# AY10
TP1 BG26
TP2 BJ26
TP3 BH25
TP4 BJ16
TP5 BG16
TP6 AH38
TP7 AH37
TP8 AK43
TP9 AK45
TP10 C18
TP11 N30
TP12 H3
TP13 AH12
TP14 AM4
TP15 AM5
TP16 Y13
TP17 K24
TP18 L24
TP19 AB46
Mobile PCH Ball
Name
Ball #
TP20 AB45
TP21 B21
TP22 M20
TP23 AY16
TP24 BG46
TP25 BE28
TP26 BC30
TP27 BE32
TP28 BJ32
TP29 BC28
TP30 BE30
TP31 BF32
TP32 BG32
TP33 AV26
TP34 BB26
TP35 AU28
TP36 AY30
TP37 AU26
TP38 AY26
TP39 AV28
TP40 AW30
USBP0N C24
USBP0P A24
USBP1N C25
USBP1P B25
USBP2N C26
USBP2P A26
USBP3N K28
USBP3P H28
USBP4N E28
USBP4P D28
USBP5N C28
USBP5P A28
USBP6N C29
USBP6P B29
USBP7N N28
USBP7P M28
USBP8N L30
USBP8P K30
USBP9N G30
USBP9P E30
USBP10N C30
USBP10P A30
USBP11N L32
USBP11P K32
USBP12N G32
Mobile PCH Ball
Name
Ball #
USBP12P E32
USBP13N C32
USBP13P A32
USBRBIAS B33
USBRBIAS# C33
V_PROC_IO BJ8
V5REF P34
V5REF_Sus M26
Vcc3_3 AJ2
Vcc3_3 T34
Vcc3_3 AA16
Vcc3_3 W16
Vcc3_3 T38
Vcc3_3 BH29
Vcc3_3 V33
Vcc3_3 V34
VccAClk AD49
VccADAC U48
VccADPLLA BD47
VccADPLLB BF47
VccAFDIPLL BG6
VccALVDS AK36
VccAPLLDMI2 BH23
VccAPLLEXP BJ22
VccAPLLSATA AK1
VccASW T19
VccASW V21
VccASW T21
VccASW AA19
VccASW AA21
VccASW AA24
VccASW AA26
VccASW AA27
VccASW AA29
VccASW AA31
VccASW AC26
VccASW AC27
VccASW AC29
VccASW AC31
VccASW AD29
VccASW AD31
VccASW W21
VccASW W23
VccASW W24
VccASW W26
Mobile PCH Ball
Name
Ball #
