Datasheet 293

Package Information

7 Package Information

7.1 Desktop PCH package

• FCBGA package

• Package size: 27 mm x 27 mm

• Ball Count: 942

• Ball pitch: 0.7 mm

The Desktop PCH package information is shown in Figure 7-1.

Note: All dimensions, unless otherwise specified, are in millimeters.
