Datasheet 295

Package Information

7.2 Mobile PCH Package

• FCBGA package

• Package size: 25 mm x 25 mm

• Ball Count: 989

• Ball pitch: 0.6 mm

The Mobile PCH package information is shown in Figure 7-2

Note: All dimensions, unless otherwise specified, are in millimeters.
