Datasheet 319

Electrical Characteristics

Frequency = 85–MHz

TPPos0

Transmitter Output

Pulse for Bit 0

-0.20 0 0.20 ns

Figure 8-27

TPPos1

Transmitter Output

Pulse for Bit 1

1.48 1.68 1.88 ns

TPPos2

Transmitter Output

Pulse for Bit 2

3.16 3.36 3.56 ns

TPPos3

Transmitter Output

Pulse for Bit 3

4.84 5.04 5.24 ns

TPPos4

Transmitter Output

Pulse for Bit 4

6.52 6.72 6.92 ns

TPPos5

Transmitter Output

Pulse for Bit 5

8.20 8.40 8.60 ns

TPPos6

Transmitter Output

Pulse for Bit 6

9.88 10.08 10.28 ns

TJCC

Transmitter Jitter

Cycle-to-Cycle

——250ps

Frequency = 108–MHz

TPPos0

Transmitter Output

Pulse for Bit 0

-0.20 0 0.20 ns

Figure 8-27

TPPos1

Transmitter Output

Pulse for Bit 1

1.12 1.32 1.52 ns

TPPos2

Transmitter Output

Pulse for Bit 2

2.46 2.66 2.86 ns

TPPos3

Transmitter Output

Pulse for Bit 3

3.76 3.96 4.16 ns

TPPos4

Transmitter Output

Pulse for Bit 4

5.09 5.29 5.49 ns

TPPos5

Transmitter Output

Pulse for Bit 5

6.41 6.61 6.81 ns

TPPos6

Transmitter Output

Pulse for Bit 6

7.74 7.94 8.14 ns

TJCC

Transmitter Jitter

Cycle-to-Cycle

——250ps

Table 8-22. LVDS Interface AC characteristics at Various Frequencies (Sheet 2 of 2)

Symbol Parameter Min Nom Max Unit Figures Notes
