Datasheet 495
LPC Interface Bridge Registers (D31:F0)
13.5.5 ID—Identification Register
Index Offset: 00h Attribute: R/W
Default Value: 00000000h Size: 32 bits
The APIC ID serves as a physical name of the APIC. The APIC bus arbitration ID for the
APIC is derived from its I/O APIC ID. This register is reset to 0 on power-up reset.
13.5.6 VER—Version Register
Index Offset: 01h Attribute: RO, R/WO
Default Value: 00170020h Size: 32 bits
Each I/O APIC contains a hardwired Version Register that identifies different
implementation of APIC and their versions. The maximum redirection entry information
also is in this register, to let software know how many interrupt are supported by this
APIC.
Bit Description
31:28 Reserved
27:24 APIC ID — R/W. Software must program this value before using the APIC.
23:16 Reserved
15 Scratchpad Bit.
14:0 Reserved
Bit Description
31:24 Reserved
23:16
Maximum Redirection Entries (MRE) — R/WO. This is the entry number (0 being
the lowest entry) of the highest entry in the redirection table. It is equal to the number
of interrupt input pins minus one and is in the range 0 through 239. In the PCH this
field is hardwired to 17h to indicate 24 interrupts.
BIOS must write to this field after PLTRST# to lockdown the value. this allows BIOS to
utilize some of the entries for its own purpose and thus advertising fewer IOxAPIC
Redirection Entries to the OS.
15
Pin Assertion Register Supported (PRQ) — RO. Indicate that the IOxAPIC does not
implement the Pin Assertion Register.
14:8 Reserved
7:0
Version (VS) — RO. This is a version number that identifies the implementation
version.
