LPC Interface Bridge Registers (D31:F0)
504 Datasheet
13.7.2 NMI_EN—NMI Enable (and Real Time Clock Index)
Register
I/O Address: 70h Attribute: R/W (special)
Default Value: 80h Size: 8-bit
Lockable: No Power Well: Core
Note: The RTC Index field is write-only for normal operation. This field can only be read in Alt-
Access Mode. Note, however, that this register is aliased to Port 74h (documented in
Table 13-6), and all bits are readable at that address.
13.7.3 PORT92—Fast A20 and Init Register
I/O Address: 92h Attribute: R/W
Default Value: 00h Size: 8-bit
Lockable: No Power Well: Core
13.7.4 COPROC_ERR—Coprocessor Error Register
I/O Address: F0h Attribute: WO
Default Value: 00h Size: 8-bits
Lockable: No Power Well: Core
Bits Description
7
NMI Enable (NMI_EN) — R/W (special).
0 = Enable NMI sources.
1 = Disable All NMI sources.
6:0
Real Time Clock Index Address (RTC_INDX) — R/W (special). This data goes to
the RTC to select which register or CMOS RAM address is being accessed.
Bit Description
7:2 Reserved
1
Alternate A20 Gate (ALT_A20_GATE) — R/W. This bit is Or’d with the A20GATE
input signal to generate A20M# to the processor.
0 = A20M# signal can potentially go active.
1 = This bit is set when INIT# goes active.
0
INIT_NOW — R/W. When this bit transitions from a 0 to a 1, the PCH will force INIT#
active for 16 PCI clocks.
Bits Description
7:0
Coprocessor Error (COPROC_ERR) — WO. Any value written to this register will
cause IGNNE# to go active, if FERR# had generated an internal IRQ13. For FERR# to
generate an internal IRQ13, the COPROC_ERR_EN bit must be 1.
