NOTE: RSMRST# is sampled using the RTC clock. Therefore, low times that are less than one RTC
clock period may not be detected by the PCH.
5:4
SLP_S4# Minimum Assertion Width — R/W. This field indicates the minimum
assertion width of the SLP_S4# signal to ensure that the DRAM modules have been
safely power-cycled.
Valid values are:
11 = 1 second
10 = 2 seconds
01 = 3 seconds
00 = 4 seconds
This value is used in two ways:
1. If the SLP_S4# assertion width is ever shorter than this time, a status bit is
set for BIOS to read when S0 is entered.
2. If enabled by bit 3 in this register, the hardware will prevent the SLP_S4#
signal from deasserting within this minimum time period after asserting.
RTCRST# forces this field to the conservative default state (00b).
NOTES:
1. This field is RO when the SLP Stretching Policy Lock-Down bit is set.
2. Note that the logic that measures this time is in the suspend power well.
Therefore, when leaving a G3 or Deep S4/S5 state, the minimum time is
measured from the deassertion of the internal suspend well reset (unless
the “Disable SLP Stretching After SUS Well Power Up” bit is set).
3
SLP_S4# Assertion Stretch Enable — R/W.
0 = The SLP_S4# minimum assertion time is defined in Power Sequencing and
Reset Signal Timings table.
1 = The SLP_S4# signal minimally assert for the time specified in bits 5:4 of this
register.
This bit is cleared by RTCRST#.
NOTE: This bit is RO when the SLP Stretching Policy Lock-Down bit is set.
2
RTC Power Status (RTC_PWR_STS) — R/W. This bit is set when RTCRST#
indicates a weak or missing battery. The bit is not cleared by any type of reset. The
bit will remain set until the software clears it by writing a 0 back to this bit position.
1
Power Failure (PWR_FLR) — R/WC. This bit is in the DeepS4/S5 well and
defaults to 1 based on DPWROK deassertion (not cleared by any type of reset).
0 = Indicates that the trickle current has not failed since the last time the bit was
cleared. Software clears this bit by writing a 1 to it.
1 = Indicates that the trickle current (from the main battery or trickle supply) was
removed or failed.
NOTE: Clearing CMOS in a PCH-based platform can be done by using a jumper on
RTCRST# or GPI. Implementations should not attempt to clear CMOS by
using a jumper to pull VccRTC low.
0
AFTERG3_EN — R/W. This bit determines what state to go to when power is re-
applied after a power failure (G3 state). This bit is in the RTC well and is only
cleared by writes of 06h or 0Eh to CF9h (when the CF9h global reset bit is clear),
receiving hard reset command with or without power cycle from SMBus or
RTCRST#.
0 = System will return to S0 state (boot) after power is re-applied.
1 = System will return to the S5 state (except if it was in S4, in which case it will
return to S4). In the S5 state, the only enabled wake event is the Power
Button or any enabled wake event that was preserved through the power
failure.
Bit Description
