Datasheet 615
SATA Controller Registers (D31:F2)
14.4.2.13 PxSACT—Port [5:0] Serial ATA Active (D31:F2)
Address Offset: Port 0: ABAR + 134h Attribute: R/W
Port 1: ABAR + 1B4h
Port 2: ABAR + 234h (if port available; see Section 1.3)
Port 3: ABAR + 2B4h (if port available; see Section 1.3)
Port 4: ABAR + 334h
Port 5: ABAR + 3B4h
Default Value: 00000000h Size: 32 bits
14.4.2.14 PxCI—Port [5:0] Command Issue Register (D31:F2)
Address Offset: Port 0: ABAR + 138h Attribute: R/W
Port 1: ABAR + 1B8h
Port 2: ABAR + 238h (if port available; see Section 1.3)
Port 3: ABAR + 2B8h (if port available; see Section 1.3)
Port 4: ABAR + 338h
Port 5: ABAR + 3B8h
Default Value: 00000000h Size: 32 bits
§ §
Bit Description
31:0
Device Status (DS) — R/W. System software sets this bit for SATA queuing operations
prior to setting the PxCI.CI bit in the same command slot entry. This field is cleared
using the Set Device Bits FIS.
This field is also cleared when PxCMD.ST (ABAR+118h/198h/218h/298h:bit 0) is
cleared by software, and as a result of a COMRESET or SRST.
Bit Description
31:0
Commands Issued (CI) — R/W. This field is set by software to indicate to the PCH
that a command has been built-in system memory for a command slot and may be sent
to the device. When the PCH receives a FIS which clears the BSY and DRQ bits for the
command, it clears the corresponding bit in this register for that command slot. Bits in
this field shall only be set to 1 by software when PxCMD.ST is set to 1.
This field is also cleared when PxCMD.ST (ABAR+118h/198h/218h/298h:bit 0) is
cleared by software.
