DMTA-10045-01EN, Rev. E, August 2016
Chapter 5 108
EDIT
Using the EDIT function, you can edit the name of a file and add FILE NOTES
(text) to the stored data.
To add or edit text (FILE NAME or FILE NOTE) of a stored data file, press the
MEM menu key ( ), rotate the knob until the desired data file is highlighted,
and then press the C key; a text editor will appear on the BondMaster 600 display.
For more information, see “Memory Text Editor” on page 109.
SET REF (set reference image)
While performing inspections, you can use the SET REF function to display a
saved screen image on the BondMaster 600 display in a contrasting color. This
reference image remains on the display until the SET REF function is turned off.
To display a reference image, press the MEM menu key ( ), rotate the knob
until the desired data file is highlighted, and then press the D key. Alternatively, a
reference image may be created using the current screen image by pressing and
holding the REF SAVE direct function key ( ) until the BondMaster 600 emits a
sound alert.
To turn off a reference image, press the MEM menu key ( ), and then press
the E key.
An error message will appear when turning on the SET REF (set reference) function if
the selected RUN (display mode) as recorded in the file is not compatible with the
currently active RUN.
For example, an error message occurs if you try to activate a SET REF image that is
configured to the RF + XY RUN mode when the current RUN mode is RF SIGNAL.
ERASE
Use this function to erase a program number (stored data file).
To erase a stored data file, press the MEM menu key ( ), rotate the knob until
the desired data file is highlighted, and then press the E key.
NOTE
