DMTA-10045-01EN, Rev. E, August 2016
Chapter 5
118
○ VIDEO TEST—Checks the BondMaster 600 by displaying three equal-
width color bands: red, green, and blue. The test fails if one or more of the
equal-width bands is not present. To exit the video test, press the Return
key ( ). Subsequently, the TESTS menu reappears on the
BondMaster 600 display.
○ KEYPAD TEST—Checks if the BondMaster 600 keypad is operating
correctly and displays the last key that was pressed. The test continues
until the Return key ( ) is pressed. Subsequently, the TESTS menu
reappears on the BondMaster 600 display.
○ SD CARD TEST—Checks the internal SD card and external SD card (if
present), and presents a PASSED or FAILED response. To exit the SD
card test, press the Return key ( ). Subsequently, the TESTS menu
reappears on the BondMaster 600 display.
If an external SD card is not present during the SD card test, FAILED is displayed for
this storage device.
○ LED TEST—Checks if the BondMaster 600 LEDs (light-emitting diodes)
are operational. The LEDs are located at the top-left corner of the
BondMaster 600, and are marked with the numbers 1, 2, and 3. During
the test, each of the LEDs consecutively illuminate in a sequence of green,
yellow/orange, and red. If any of these colors are not present, that LED is
not working correctly. To exit the LED test, press the Return key ( ).
Subsequently, the TESTS menu reappears on the BondMaster 600
display.
The battery or charging indicator LED is not tested during the LED TEST and can
instead be manually inspected. For more information on this LED, see
“Charger/Adaptor” on page 29.
RESET
Provides the ability to reset the BondMaster 600 as follows:
