REF/SAVE Direct function key used to save images
and settings in the BondMaster 600
memory. When this key is pressed once
(and released), the currently displayed
image and settings are saved. When this
key is pressed and held, the current
BondMaster 600 image is set as the
reference memory display.
MAIN Provides access to the main menu, which
controls functions such as frequency, gain,
angle, filters, RF signal, and gate.
DISP/DOTS Provides access to the display menu, which
controls functions such as display mode,
position, trace, grid. Also allows you to add
reference dots (not available in PC Swept
mode).
ALARM Provides access to the alarm menu, which
controls functions such as alarm type,
dwell time, horn, and alarm position.
MEM Provides access to the memory menu,
which controls functions such as
previewing stored memory files, recalling
and editing stored files, capture mode,
capture time, and user information.
ADV/SETUP Provides access to the BondMaster 600
advanced settings, including the
APPLICATION SELECTION menu, the
ALL SETTINGS menu, instrument mode,
colors, password, systems setup, reset,
calibration menu, unlock options, and
legal/regulatory information.
