DMTA-10045-01EN, Rev. E, August 2016
Control Functions
79
Changing the Parameters in the PC Swept Main Menu
The following information is applicable when the BondMaster 600 is set to PC Swept
mode and the MAIN menu key ( ) has been pressed.
ANGLE
The ANGLE setting controls the rotation of the display signal.
To change the ANGLE setting, press the A key, and then rotate the knob to the
desired angle value.
GAIN (H/V GAIN)
The GAIN setting controls the overall gain of the signal.
To change the GAIN setting, press the MAIN menu key ( ) once, then press
the B key and rotate the knob to the desired setting.
START FREQ (start frequency)
The START FREQ (start frequency) setting controls the swept frequency starting
point (value).
To change the START FREQ setting, press the C key, and then rotate the knob to
the desired start frequency value.
STOP FREQ (stop frequency)
The STOP FREQ (stop frequency) setting controls the swept frequency ending
point (value).
To change the STOP FREQ setting, press the D key, and then rotate the knob to
the desired stop frequency value.
SW. RATE (swept rate)
The SW. RATE (swept rate) setting controls the swept rate and can be set to one of
the following options: LOW, MEDIUM, or HIGH.
To change the SW. RATE setting, press the E key, and then rotate the knob to the
desired swept rate value.
