Processing
● Sets the send buffer in the message body data specified by [S]. The data created by the
CIPMSET instruction can be used as the contents of the message body data.
Message body data
Higher byte Lower byte
1 word
Message body size (0 to 502 bytes)
2 words
Message body data
:
(Note 1) For details about the commands and responses, refer to relevant manuals for each EtherNet/IP
device.
■
Examples of the maximum service data size
---: Omitted
Service
code
Size Segment Class ID Segment
Instance
ID
Segment
Attirubte
ID
Service
data
1 1byte 0x00 - - - - - - Max. 502
(bytes)
2 1byte 0x01 0x20 1byte - - - - Max. 500
(bytes)
3 1byte 0x02 0x0021 2byte - - - - Max. 498
(bytes)
4 1byte 0x02 0x20 1byte 0x24 1byte - - Max. 498
(bytes)
5 1byte 0x03 0x20 1byte 0x0025 2byte - - Max. 496
(bytes)
6 1byte 0x03 0x0021 2byte 0x24 1byte - - Max. 496
(bytes)
7 1byte 0x04 0x0021 2byte 0x0025 2byte - - Max. 494
(bytes)
8 1byte 0x03 0x20 1byte 0x24 1byte 0x30 1byte Max. 496
(bytes)
9 1byte 0x04 0x20 1byte 0x24 1byte 0x0031 2byte Max. 494
(bytes)
10 1byte 0x04 0x20 1byte 0x0025 2byte 0x30 1byte Max. 494
(bytes)
11 1byte 0x05 0x20 1byte 0x0025 2byte 0x0031 2byte Max. 492
(bytes)
12 1byte 0x04 0x0021 2byte 0x24 1byte 0x30 1byte Max. 494
(bytes)
13 1byte 0x05 0x0021 2byte 0x24 1byte 0x0031 2byte Max. 492
(bytes)
14 1byte 0x05 0x0021 2byte 0x0025 2byte 0x30 1byte Max. 492
(bytes)
17.31 EIPMBODY (EIP Message Body Setting)
17-156 WUME-FP7CPUPGR-12
