Panasonic FP7 Series Command Reference Manual

5.17 LCRD (Specified PB Local Device Read)
■
Ladder diagram
■
Available operation units (●: Available)
Operatio
n unit
bit US SS UL SL SF DF
i ● ● ● ●
■
List of operands
Operand Description
PBm Source PB number (Available range: 1 to Max. number of PB)
S Starting address of source local device
n Number of read devices (Available range: 1 to 65535)
D Starting address of readout destination device
■
Available devices (●: Available)
Operan
d
16-Bit device:
32-Bit
device:
(Note 1)
Integer
Real
numbe
r
St
rin
g
Index
modifie
r
W
X
W
Y
W
R
W
L
W
S
S
D
D
T
L
D
U
M
WI
W
O
TS
C
S
TE
C
E
IX
(N
ote
2)
K Ｕ H SF
D
F
" "
PBm ● ● ● ● ● ● ● ● ●
S ● ● ● ● ● ● ● ●
n ● ● ● ● ● ● ● ● ●
D ● ● ● ● ● ● ● ● ● ●
(Note 1) Cannot be specified when the operation unit is 16-bit integer (SS, US).
(Note 2) Index register (I0 to IE)
■
Outline of operation
● This instruction reads the data for [n] from the area specified by [PBm]:[S] (local device) to
the area specified by [D] and subsequent areas all at once.
● For [S], specify a local device that is in the program block of the PB number specified for
[PBm].
5.17 LCRD (Specified PB Local Device Read)
5-38 WUME-FP7CPUPGR-12
