Panasonic FP7 Series Command Reference Manual

7.11 DIST (Digit Disintegration)
■
Ladder diagram
■
Available operation units (●: Available)
Operatio
n unit
bit US SS UL SL SF DF
i ●
■
List of operands
Operand Description
S
The device address where the data to be broken down are stored, or the constant (data format:
according to the operation unit)
n
The device address where the number of points into which the data is broken down is stored, or the
constant (data format: unsigned 16-bit integer)
D Storage device address (data format: unsigned 16-bit integer)
■
Available devices (●: Available)
Operan
d
16-Bit device:
32-Bit
device:
Integer
Real
numbe
r
St
rin
g
Index
modifie
r
(Note 1)
W
X
W
Y
W
R
W
L
W
S
S
D
D
T
L
D
U
M
WI
W
O
TS
C
S
TE
C
E
IX K Ｕ H SF
D
F
" "
S ● ● ● ● ● ● ● ● ● ● ● ● ● ●
n ● ● ● ● ● ● ● ● ● ● ● ● ● ●
D ● ● ● ● ● ● ● ● ●
(Note 1) Only 16-bit devices, and integer constants can be modified. (32-bit devices, real number constants,
and character constants cannot be specified.)
■
Outline of operation
● 16-bit device specified by [S] is broken down into 16-bit data by 4 bits. (The available range
for [n], the number into which the data is broken down, is 0 to 4.)
● No operation needed if [n]=0.
