Processing
0100
0011
0000 0000 0000
0000
DT20
0000 0000 0000 0001
DT21
DT22
0000 0000 0000
Example) Operation unit: 16 bits (US)
[S]…DT10 [n]…U4
[D]…DT20
0000 0000 0000
DT23
15・・・12 11・・・8 7・・・4 3・・・0
0100 0011 0001 0000
DT10
[i]…US
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set in the case of out-of-range in indirect access (index modification).
To be set when [n], the number into which the data is broken down, is out of the specified
range.
To be set when, if data equivalent to [n] is transferred from the address specified by [D], it
exceeds the device address.
7.11 DIST (Digit Disintegration)
7-26 WUME-FP7CPUPGR-12
