3.41 IMASK (Unit Interruption Disable/Enable Setting)
■
Ladder diagram
■
Available operation units (●: Available)
Operatio
n unit
bit US SS UL SL SF DF
i ●
■
List of operands
Operand Description
S Control data specifying INTPG number to disable/enable the unit interruption: H0 to HFF
D Slot number (U constant) or device number where slot number is stored
■
Devices that can be specified (indicated by ●)
Operan
d
16-Bit device:
32-Bit
device:
Integer
Real
numbe
r
St
rin
g
Index
modifie
r
W
X
W
Y
W
R
W
L
W
S
S
D
D
T
L
D
U
M
WI
W
O
TS
C
S
TE
C
E
IX K Ｕ H SF
D
F
" "
S ● ● ● ● ● ● ● ● ● ● ● ●
D ● ● ● ● ● ● ● ● ● ● ● ●
■
Outline of operation
This instruction sets to enable or disable the interruption of the unit installed in the slot specified
by [D] according to the data specified by [S].
■
Specification of [S]
bit no.
15 0
INTPG 7
INTPG 0
0 0 0 0 0 0 0 0
8 7
0: Disable 1: Enable
Higher 8 bits 0: Fixed
