Panasonic FP7 Series Command Reference Manual

3.20 CT (Down Counter)
■
Ladder diagram
■
List of operands
Operand Description
n Counter number
S Counter set value
■
Devices that can be specified (indicated by ●)
Operan
d
16-Bit device:
32-Bit
device:
Integer
Real
numbe
r
St
rin
g
Index
modifie
r
W
X
W
Y
W
R
W
L
W
S
S
D
D
T
L
D
U
M
WI
W
O
TS
C
S
(N
ote
1)
TE
C
E
IX K Ｕ H SF
D
F
" "
n ● ●
S ● ● ● ● ● ● ● ● ●
(Note 1) Only CS can be specified for CT instruction.
■
Outline of operation
● All counters are decremental preset counters.
● When the reset input rises from OFF to ON, the value in the set value area "CS" is preset to
the elapsed value area "CE."
● When the reset input is ON, the elapsed value is reset to 0.
● When the count input changes from OFF to ON, the counter decrements from the set value.
When the elapsed value becomes 0, output to the counter contact is generated.
3.20 CT (Down Counter)
WUME-FP7CPUPGR-12 3-53
