9.6 CLC (Carry-Flag Reset)

■

Ladder diagram

■

Outline of operation

This instruction turns OFF SR9 (CY).

■

Flag operations

Name Description

SR9 (CY) To be reset after this instruction is executed.

9.6 CLC (Carry-Flag Reset)

WUME-FP7CPUPGR-12 9-11
