14.37 ESREP (Replacement of a String: With Storage Area Size)
Ladder diagram
List of operands
Operand Description
S
Starting device address of the source string (available range: 0 to 65534; for character constant: 0
to 256 characters)
D Starting device address of the destination string (available range: 1 to 65534)
p Replacement start position of the destination string (available range: 0 to 65533)
n Number of characters to be replaced (available range: 0 to 65534)
Available devices (●: Available)
Operan
d
16-Bit device:
32-Bit
device:
Integer
Real
numbe
r
St
rin
g
Index
modifie
r
(Note 1)
W
X
W
Y
W
R
W
L
W
S
S
D
D
T
L
D
U
M
WI
W
O
TS
C
S
TE
C
E
IX K H SF
D
F
" "
S
D
p
n
(Note 1) Only 16-bit devices, and integer constants can be modified. (Character constants cannot be specified.)
Outline of operation
This instruction replaces the string specified by [D] with the string specified by [S].
For [p], specify the relative position in [D] where the string is replaced, and for [n] specify the
number of characters to be replaced.
Processing
Example 1) Taking out the five characters "ABCDE" from the DT0 string to transfer
them to the 1st byte (2nd character) of the DT20 string
[S]...DT0 [D]...DT20 [p]...U1 [n]...U3
14.37 ESREP (Replacement of a String: With Storage Area Size)
14-142 WUME-FP7CPUPGR-12
