14.3 HEXA (Conversion: HEX → Hexadecimal ASCII)
■
Ladder diagram
■
Available operation units (●: Available)
Operatio
n unit
bit US SS UL SL SF DF
i ● ● ● ●
■
List of operands
Operand Description
S1 Starting number for the area storing the hexadecimal numeric values
S2 The area that stores the length (number of bytes) to be converted, or the constant
D Starting number of the area that stores the ASCII code as the conversion result
■
Available devices (●: Available)
Operan
d
16-Bit device:
32-Bit
device:
Integer
Real
numbe
r
St
rin
g
Index
modifie
r
(Note 1)
W
X
W
Y
W
R
W
L
W
S
S
D
D
T
L
D
U
M
WI
W
O
TS
C
S
TE
C
E
IX
K
(N
ote
2)
Ｕ
(N
ote
3)
H
(N
ote
4)
SF
D
F
" "
S1 ● ● ● ● ● ● ● ● ●
S2 ● ● ● ● ● ● ● ● ● ●
D ● ● ● ● ● ● ●
(Note 1) Only 16-bit devices, 32-bit devices, and integer constants can be modified. (Real number constants,
and character constants cannot be specified.)
(Note 2) Can be specified only when the operation unit is signed integer (SS, SL).
(Note 3) Can be specified only when the operation unit is unsigned integer (US, UL).
(Note 4) Can be specified only when the operation unit is integer (US, SS, UL, SL).
■
Outline of operation
● This instruction converts a hexadecimal figure into an ASCII code.
● The hexadecimal numerical data stored in the area specified by [S1] is converted into an
ASCII code and stored in the area specified by [D].
● [S2] specifies the number of data bytes to be converted.
14.3 HEXA (Conversion: HEX → Hexadecimal ASCII)
14-10 WUME-FP7CPUPGR-12
