Panasonic FP7 Series Command Reference Manual

15.10 CONFIG (Change Configuration)
■
Ladder diagram
■
List of operands
Operand Description
S1
Specify the character constant or the starting address of the device storing the string data that
indicates the configuration type.
S2
Specify the character constant or the starting address of the device storing the string data that
indicates the contents of change of the configuration.
■
Available devices (●: Available)
Operan
d
16-Bit device:
32-Bit
device:
Integer
Real
numbe
r
St
rin
g
Index
modifie
r
W
X
W
Y
W
R
W
L
W
S
S
D
D
T
L
D
U
M
WI
W
O
TS
C
S
TE
C
E
IX K Ｕ H SF
D
F
" "
S1 ● ● ● ● ● ● ●
S2 ● ● ● ● ● ● ●
■
Outline of operation
● When “MEWTOCOL” is specified for [S1]
This instruction configures the settings so that reception is possible if the MEWTOCOL-
COM(RD,WD) or MEWTOCOL-DAT(50H,51H) command is used to specify a device FL from
another FP series PLC. This function is compatible with FP2SH.
This instruction can be used for an FP7 CPU unit with built-in SCU, built-in ET-LAN, or Serial
Communication Unit.
Specify whether to assign data to FL0 or to the device number (DT/LD) of the FP7 CPU unit,
if FL is specified by the partner device for MEWTOCOL-COM or MEWTOCOL-DAT
communication.
● When “TCP-NODELAY” is specified for [S1]
Possible to change the enable/disable setting for the TCP-NODELAY option between all
system connections and user connection.
While communication is performed with a device that is set with TCP delay ACK, high-speed
communication becomes possible if the TCP-NODELAY option is enabled.
The state of the enable/disable setting for the TCP-NODELAY option can be confirmed using
the TCP-NODELAY option flag (X63).
When the power is turned ON, the TCP-NODELAY option is disabled. After this instruction is
executed, the TCP-NODELAY option is enabled.
15.10 CONFIG (Change Configuration)
WUME-FP7CPUPGR-12 15-65
