In this example, a 0.1-second timer with the timer number 5 is set to 3.0 seconds. It starts
counting time when X100 is ON, and the contact T5 turns ON when the timer reaches 3.0
seconds.
Control Instructions
These are a group of instructions that determine the order and flow for executing a program.
Conditions can be set to modify parts of a program to be executed, or to execute necessary
parts only.
Major control instructions include the following.
Mnemonic Name Function
MC-MCE Master control relay
When execution conditions are OFF, output between MC and MCE are
turned OFF.
JP/LBL Jump label
Jumps to the LBL instruction with the same number when the
execution condition is ON. When LBL instruction is in an address that
comes after JP instruction, the programs between JP and LBL are not
executed, so the operation time is shortened.
LOOP/LBL Loop label
When execution conditions are ON, the part of a program between LBL
and LOOP is repeated for specified times.
Step ladder instructions
These instructions handle a section specified by SSTP to STPE as an independent
"process", and operate sequential execution or branch execution.
Subroutine instructions
These instructions call and execute subroutines when necessary. Subroutines are programs
for repeated execution of operations, etc., as specified by SBL and RET.
Data comparison instructions
These are a group of instructions for comparing two sets of data. They operate as a contact that
turns ON and OFF in accordance with the comparison result.
2.1.2 Structural patterns of high-level instructions
Structure of high-level instructions
Mnemonics indicate the specifics of operation (e.g. data transfer, arithmetic operation).
Operation units indicate the units for operation triggered by instructions (e.g. US, SS, UL, SL,
SF, DF).
2.1 Structure of Instructions
2-4 WUME-FP7CPUPGR-12
