7.7 DECO (Decoding)
■
Ladder diagram
■
List of operands
Operand Description
S The device address where the data for decoding are stored, or the constant
n
The device address where the control data (specification of the conversion starting bit, specification
of the conversion-enabled bit length) are stored, or the constant
D Storage device address
■
Available devices (●: Available)
Operan
d
16-Bit device:
32-Bit
device:
Integer
Real
numbe
r
St
rin
g
Index
modifie
r
(Note 1)
W
X
W
Y
W
R
W
L
W
S
S
D
D
T
L
D
U
M
WI
W
O
TS
C
S
TE
C
E
IX K Ｕ H SF
D
F
" "
S ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●
n ● ● ● ● ● ● ● ● ● ● ● ● ●
D ● ● ● ● ● ● ● ● ●
(Note 1) Only 16-bit devices, and integer constants can be modified. (Real number constants, and character
constants cannot be specified.)
■
Outline of operation
● This instruction decodes a value of the device address or the constant specified by [S], and
stores the result in the device address specified by [D].
● The part to be decoded is specified by control data [n].
● The required length of the device address for storing the result depends on the length of the
data before decoding.
7.7 DECO (Decoding)
7-14 WUME-FP7CPUPGR-12
