7.5 BCD (Conversion: BCD Data)
■
Ladder diagram
■
Available operation units (●: Available)
Operatio
n unit
bit US SS UL SL SF DF
i ● ●
■
List of operands
Operand Description
S The device address where the binary data to be converted is stored, or the constant
D Device address to store the conversion result
■
Available devices (●: Available)
Operan
d
16-Bit device:
32-Bit
device:
Integer
Real
numbe
r
St
rin
g
Index
modifie
r
W
X
W
Y
W
R
W
L
W
S
S
D
D
T
L
D
U
M
WI
W
O
TS
C
S
TE
C
E
IX K Ｕ H SF
D
F
" "
S ● ● ● ● ● ● ● ● ● ● ●
D ● ● ● ● ● ● ●
■
Outline of operation
This instruction converts the device address value or the constant specified by [S] from binary
data to BCD data, and stores the result in the device specified by [D].
